Name: Leuze DCR 1048i ADJ-8F4-102-M4 Stationary 2D-code reader
Brand: Leuze
SKU: 50147803
Price: 106800.0 INR
Availability: OutOfStock

Leuze DCR 1048i ADJ-8F4-102-M4 Stationary 2D-code reader

Non-returnable

Price:

₹106,800.00

ENQUIRE NOW

Leuze DCR 1048i ADJ-8F4-102-M4 is a high-speed stationary 2D code reader with a 1440×1080 px sensor, global shutter, and integrated red/white illumination. It supports 1D/2D code reading, features Ethernet/PROFINET communication, and offers reliable performance for industrial automation.

Product Details

• Description : Leuze DCR 1048i ADJ-8F4-102-M4 is a high-speed stationary 2D code reader with a 1440×1080 px sensor, global shutter, and integrated red/white illumination. It supports 1D/2D code reading, features Ethernet/PROFINET communication, and offers reliable performance for industrial automation.

• Product Full Name : 1. Power Supply: 18–30 V DC 2. Power Consumption: Max 24 W 3. Digital I/Os: 3 Inputs, 5 Outputs (protected) 4. Image Sensor: 1440 × 1080 px (Sony global shutter) 5. Lens: 8 mm adjustable focus 6. Reading Distance: 50 – 2000 mm 7. Minimum Code Size: 0.127 mm 8. Lighting: Integrated red/white LED 9. Interface: Ethernet, PROFINET 10. Protocols: TCP/IP, UDP, FTP, PROFINET RT 11. Ethernet Port: M12 X-coded (10/100 Mbps) 12. Operating Temp: 0 to +50 °C 13. Housing: Industrial-grade (diecast zinc)

Product Datasheet
