Janatics - Aluminum Male Connector 6 mm x 1/4''
Customize
Product Details
Janatics WP2110651 Male Connector is a WP2 Series pneumatic one-touch fitting designed to connect 6 mm OD tubing to an R1/4 male threaded port.
The fitting uses a push-in connection system that allows the pneumatic tube to be inserted quickly and removed by pressing the collet cap. Janatics specifies the WP2 series for Nylon and Polyurethane tubing, with a stainless-steel collet and Teflon pre-coated male taper threads to support secure, leak-resistant pneumatic connections.
The connector is suitable for compressed-air circuits in pneumatic cylinders, directional valves, air-preparation units, control panels and industrial machinery.
Technical Details
- Brand: Janatics
- Ordering No.: WP2110651
- Series: WP2
- Product Type: Straight Male Connector / One-Touch Fitting
- Applicable Tube OD: 6 mm
- Thread: R1/4 Male
- Thread Type: BSP Taper / R Thread
- Hex Size: 14 mm
- Overall Length L1: 25.5 mm
- Length L2: 20 mm
- Tube Insertion Length A: 15.5 mm
- Medium: Compressed Air
- Maximum Operating Pressure: 10 bar
- Ambient Temperature: -10°C to +60°C
- Medium Temperature: +5°C to +50°C
- Applicable Tube Material: Nylon / Polyurethane
- Recommended Tube OD Tolerance: ±0.1 mm
- Connection Style: Push-in / One-Touch
- Male Thread Treatment: Teflon pre-coated
- Housing: Metal housing with plastic collet cap
Suitable Applications
Pneumatic cylinders, solenoid and directional valves, FRL units, pneumatic control panels, machinery air lines and general compressed-air installations.
