Moons stepper drive SR3-mini
₹4,421.00
Supply Voltage:12VDC-48VDC, Output Current(peak):0.4Amps-3Amps, Step Resolutions(1.8°Stepper): Full Step, 2x, 4x, 5x, 8x, 10x, 16x, 20x, 25x, 30x, 32x, 40x, 50x, 64x, 100x, 128x Microstepping, Step Pulse Frequency:500KHz Max, Selectable Damping Modes For Smooth Motion
Features / Functions
1. Compact Design. 2. Wide Voltage Range. 3. High-Precision Control. 4. Adjustable Current Output. 5. Easy Setup and Configuration. 6. Cost-Effective. 7. Flexible Connectivity. Specifications
1. Input Voltage: 12VDC to 48VDC. 2. Output Current: Adjustable from 0.4A to 3A. 3. Supported Motor Type: Two-phase stepper motors. 4. Protection Features: Over-voltage, under-voltage, over-current, over-temperature. 5. Control Mode: Pulse and direction inputs. Choose Quantity
