Leuze
Leuze KD S-M12-8A-P1-050 - Connection cable
SKU - 50135128
₹1,500.00
Customize
Product Full Name :
1.Part Number: 50135128 2.Cable Length: 5 meters (5,000 mm) 3.Connection 1: M12 axial female connector, 8-pin, A-coded 4.Connection 2: Open end (unterminated) 5.Operating Voltage: Up to 30 V AC/DC 6.Sheathing Material: Polyurethane (PUR) 7.Sheathing Color: Black 8.Shielded: Yes 9.Halogen-Free: Yes 10.Temperature Range: During assembly/handling: -20°C to +80°C After installation (without vibration): -40°C to +80°C 11.Degree of Protection: IP65 12.Cable Type: Multi-core ble for Drag Chains: Yes 14.Torsion Suitability: ±30°/m (up to 2 million cycles at 35 cycles/min) 15.Bending Radius: Flexible laying: ≥10× cable diameter Stationary laying: ≥5× cable diameter 16.Outer Sheathing Properties: Free of CFC, cadmium, silicone, halogen, and lead Matt finish, low-adhesion, abrasion-resistant Easily machine-processable 17.Chemical Resistance: Hydrolysis and microbe resistant Good resistance to oil, gasoline, and chemicals (per VDE 0472 part 803 test B) Flame retardant (UL 1581 VW1 / CSA FT1 / IEC 60332-1, IEC 60332-2-2) Full Product Name
Description :
Operating voltage 30 V AC/DC Connection Connection 1 Type of connection Connector Thread size M12 Type Female No. of pins 8 -pin Encoding A-coded Design Axial Connection 2 Type of connection Open end Cable properties Number of conductors 8 Piece(s) Sheathing color Black Shielded Yes Silicone-free Yes Cable length 5,000 mm Sheathing material PUR Wire insulation PP Suitability for drag chains Yes In stock:
2
